Formaldehyde Sensor (CH2O) | 0 - 10 ppm |

Model: FD-CH2O-SENSOR
Datasheet: Click Here PDF
Availability: Usually in stock
Compatible: FD-90A-CH2O

Features

• ⚛️ High precision and long life (2 years)
• 🚄 Fast response speed, fast return to zero
• 🔋 Low power consumption, high sensitivity
• 🔬Wide linear range, strong anti-interference ability
• 💪 Excellent repeatability and stability

Description

These are generic CH2O sensors used as the pin-to-pin replacement of the standard 4-series electrochemical sensors. It is used throughout many gas detector brands and is an excellent CH2O gas sensor replacement element.

Our CH2O sensor employs an advanced electrolytic mechanism where formaldehyde and oxygen interact through precise redox reactions on specialized electrodes. By generating an electrical current directly proportional to the gas concentration, this sophisticated sensor enables accurate measurement of formaldehyde levels. The current's magnitude provides a quantitative assessment of CH2O presence in various industrial and environmental monitoring applications.

Formaldehyde detection technologies play a critical role across diverse industrial and municipal domains. From manufacturing facilities and municipal infrastructure to interior decoration and environmental monitoring, CH2O detectors provide comprehensive gas concentration insights. These advanced sensing systems enable precise measurement, early warning mechanisms, and critical monitoring, supporting public health, safety, and environmental protection in multiple application sectors.

Instructions

• Once replaced and installed in your gas detector or analyzer, please let it sit for 24 hours so the sensor can stabilize to your environment. This step is very important.
• Then undertake the appropriate zero and calibration for your specific gas detector. See your gas detector manufacturer's specific instructions.
• Once calibrated, your gas analyzer will be ready for use.

Specifications

Detection Principle	Electrochemical Three Electrodes
Detection Gas	CH2O
Detection Range	0-10 PPM
Maximum Load Concentration	50 PPM
Sensitivity (20°C)	0.55 ± 0.15 μA/ppm
Zero Drift (-20°C-50°C)	<1 ppm
Resolution	0.1 PPM
Response Time	≤90s
Bias Voltage	0 mV
Working Temperature	-20°C-50°C
Working Humidity	15%RH to 90%RH (no condensation)
Long-term Stability	<2% signal/month
Linearity	to 200 PPM
Work Pressure	90 to 110 kPa
Shelf Life	12 months after delivery
Service Life	2 years

Cross-Sensitivity Data

Interfering Gas	Gas Concentration Used (ppm)	Value Displayed (ppm CH2O)
CO	50	0.6
C2H3OH	2000	0.2
CH3COOH	2000	-0.3
C2H4	100	0.6
CH4O	100	0.3
C3H8O	100	0.2
